Screen Space Ambient Occlusion Pro
In 3D graphics, ambient occlusion is a global illumination term that measures how much ambient light can reach a surface. Poiyomi SSAO is an approximation of this shadowing that is useful for adding depth and crisp detail shadows.
This Feature is only available in Poiyomi Pro! Subscribe to the Patreon at the $10 tier or higher in order to see this module.
In order to use SSAO, you will need to place the DepthGet Prefab found in the Assets/_PoiyomiShaders/Prefabs on your avatar.
SSAO is a performance heavy effect, so use it mindfully. Add a toggle for Animatable Toggle below, and for toggling the DepthGet object. Both should be disabled by default and unsaved. In some Worlds, you can get away without activating your depth light!
Animatable Toggle
Type: Checkbox
Animate this checkbox when creating toggles for SSAO on this Material. Animating the Section Header will not work!
AO Intensity
Type: Float, Range:0.0 - 5.0
Determines how intensely AO will be blended.
AO Radius
Type: Float, Range:0.0001 - 0.02
Determines the radius tested for hemispheric visibility check. This controls how far AO shadows can spread out.
AO Quality
Type: Float, Range:2.0 - 10.0
This directly controls how many samples from the depth buffer AO takes for each pixel it is run on. If you fill your display with SSAO pixels (common when cuddling, for example) this performance cost adds up. Try starting at 4, and adding .05 jitter. Make sure you evaluate changes in-game and in VR - artifacting isn't generally as noticeable in motion.
Determines how many samples are taken and how they're distributed, whether that would be sharper or smoothened.
Lower Values will make it look more like a cel-shader, while Higher Values will make it look more smooth and cleaner.
Center Importance
Type: Float, Range:0.0 - 1.0
Weights shadows towards the source of occlusion, making shadow falloff more gradual.
Depth Bias
Type: Float, Range:0.0 - 0.2
Clips away the least intense shadows to help reduce visual artifacts.
Cone Bias
Type: Float, Range:0.0 - 1.0
Reduces shadowing on geometry that isn't actually occluded. Generally, you should use this instead of Depth bias.
Random Jitter
Type: Float, Range:0.0 - 1.0
Adds a dithered jitter effect which can help mask lower sample counts.
Use Normals
Type: Float, Range:0.0 - 1.0
0 uses vertex normals, 1 uses per-pixel normals when calculating the SSAO.
Color and Masking
Use Color Texture?
Type: Checkbox
Enables the Color Map texture slot for SSAO.
Color Map
Type: Color Texture (sRGB = On)
Color Map allows the user to map SSAO shadow color using a texture.
Use Color Mask?
Type: Checkbox
Enables the Color Mask texture slot for SSAO.
Mask
Type: Data Texture (sRGB = Off)
Color Mask allows the user to mask out certain areas from being affected by SSAO.
HSVG
Type: Float4
Color Adjust fields for SSAO. Refers to Hue, Saturation, Brightness, and Gamma.
| Channel | Function |
|---|---|
| X | Hue |
| Y | Saturation |
| Z | Value/Brightness |
| W | Gamma |
Color
Type: Color
SSAO shadow color. Black by default.
Use Surface Color
Type: Float, Range:0.0 - 1.0
Samples the color from the surface of the Material to use for the SSAO color.
Blend Mode
Type: Dropdown, Options:Repalce/Darken/Multiply/Lighten/Screen/Subtract/Add/Overlay
Which blending operation to use for the SSAO color.
Advanced & Global Masks
Hide In Light
Type: Float, Range:0.0 - 1.0
Stylistically hide SSAO under bright lighting conditions.
Quality Falloff Start
Type: Float
The distance from the camera, in meters, beyond which AO will steadily reduce quality to improve performance.
Quality Falloff End
Type: Float
The distance from the camera, in meters, beyond which AO will be completely disabled to improve performance.
Max Distance Falloff
Type: Float2
Reduce these if your AO looks like it's "reaching too far". X determines the difference in depth (beyond the radius) beyond which AO shadows will begin to attenuate. Y determines the difference in depth (beyond the radius) beyond which AO shadows will completely terminate.
Apply From Global Mask
Type: Dropdown, Options:Off/1R/1G/1B/1A/2R/2G/2B/2A/3R/3G/3B/3A/4R/4G/4B/4A
Select which Global Mask to apply to SSAO.
Apply To Global Mask
Type: Dropdown, Options:Off/1R/1G/1B/1A/2R/2G/2B/2A/3R/3G/3B/3A/4R/4G/4B/4A
Select which Global Mask SSAO writes to.
